Automatic Cup Filling and Sealing Machine

Automatic Cup Filling and Sealing Machine is suitable for kinds of shapes of plastic cups filling and sealing. The jam filling and sealing machine is an automatic capping machine developed and produced by our company, which can automatically complete filling, sealing and cutting, and print the production date. Suitable for all kinds of juice, milk, soymilk, soymilk and other plastic cup-shaped automatic capping machines. It has the characteristics of simple operation, accurate measurement, convenient maintenance, etc., and adopts a light-controlled mechanical automatic compensation mechanism to ensure the integrity of the sealing packaging pattern. It is the ideal product for your filling and sealing.

Send Inquiry

Chat Now

Introduction:

Automatic Cup Filling and Sealing Machine is a machine that can both fill and seal, and there are different models for different industries. The more commonly used industries are chemical, food and so on.

Features for jam cup filler sealer machine

The large cup paste filling and sealing machine has a wide range of uses, long service life, one-key start, high use efficiency, and is suitable for filling various products. It uses high-quality materials and strict production process. The automatic filling and sealing machine adopts a multi-structured anti-drip system, which is more accurate in quantification.

Parameter for juice cup filler sealer machine

Model	TPP-4J(1*4)
Capacity	3500-3800cups/hour
Filling head	4 heads (1,2,8,16 head welcome to consult)
Voltage	380V/50HZ
Filling method	Plug filling(leak-proof)
Filling material	Liquid or semi-liquid
Filling quantity	30-300 g adjustable
Filling accuracy	2-3 g
Power	3.5KW
Air consumption	0.65m3/m
Dimension	30008001900 mm
Weight	1200KG
Temperature control	0-400ºC

Features of automatic cup filling and sealing machine:

1. The automatic jam filling and sealing machine adopts electric and pneumatic combined transmission, and the transmission process is stable. From container supply, filling, sealing, edge trimming, product output to edge material winding, fully automated operation;

2. The automatic jam filling and sealing machine simultaneously fills, seals and trims each container, with high output and good benefits;

3. Photoelectric tracking, detecting the color code of the sealing film, and automatically correcting the position of the sealing film pattern 4. Two sets of heat-sealing devices, with tight sealing and quality assurance, can be equipped with various types of thermal coders according to customer needs to meet customer needs;

5. With a dust cover device, it is more in line with the hygiene standards of the modern food industry.


water Cup Filling Sealing Machine liquid Cup Filling and Sealing Machine

cup filler machine jam cup filler sealer
