Products Description
Introduction:
The Carrot sorting machine is a device that uses the rotation and parallel movement of stainless steel rollers to grade and sort round or oval fruits and vegetables. The rollers have gradually increased gaps, allowing fruits and vegetables to fall through the gaps according to their size, thus achieving the purpose of grading. At the same time, the rollers' rotation and rolling also facilitate manual observation and detection of unqualified fruits and vegetables.
Technical parameter:
|
model |
TPP-CG3B |
TPP-CG4B |
TPP-CG5B |
|
grades |
3 |
4 |
5 |
|
capacity |
2-3t/hr |
2-3t/hr |
2-3t/hr |
|
power |
0.75kw,380V/220V |
0.75kw,380V/220V |
0.75kw,380V/220V |
|
Dimension and weight (fruit size range 15-60mm) |
2500*1340*1000mm 460kg |
3000*1340*1000mm 500kg |
3500*1340*1000mm 540kg |
|
Dimension and weight (fruit size range 31-100mm) |
2900*1340*1000mm 490kg |
3500*1340*1000mm 540kg |
4100*1340*1000mm 590kg |
How does this carrot sorting machine work ?
Working principle:
1. Transmission: A reduction motor drives the drive shaft via a chain drive.
2. Roller Operation: The conveyor sprocket and chain on the drive shaft drive the mounted rollers, which rotate and move forward parallel to the rollers.
3. Fruit and Vegetable Tumbling and Movement: The rollers rotate on the rails of the frame. Simultaneously, gravity and rail friction cause the fruits and vegetables on the rollers to tumble 360°, moving from the drive shaft to the driven rollers.
4. Grading: The gap between the rollers gradually increases. When the fruits and vegetables reach the appropriate size, they fall through the gap and enter the hopper or conveyor belt below, where they are graded.
Machine pictures
Main Components:
1. Frame: Typically constructed of a fully welded stainless steel structure, providing excellent rigidity.
2. Rollers and Tracks: Rollers are typically constructed of mirror-finished stainless steel tubes, while tracks are constructed of food-grade plastic or rubber, meeting food hygiene standards.
3. Drive System: The carrot sorting machine Includes a reduction motor, chain drive, main drive shaft, and slave drive shafts.
4. Discharge Device: Depending on the hardness of the material, either a hopper-type or conveyor-type discharge port can be used.
Final products
Applications:
This carrot sorting machine is Mainly suitable for sorting and grading round and oval fruits and vegetables such as apples, potatoes, onions, tomatoes, plums, lychees, dates, and cherry tomatoes.
Why choose this carrot sorting machine ?
1. Damage Prevention: The material is propelled forward by the rotating rollers, preventing damage to the fruits and vegetables.
2. Manual Sorting: The rotating rollers roll the fruits and vegetables into place, allowing for comprehensive inspection and identification of defective products.
3. Customizability: Specifications, processing capacity, and grading sizes can be customized based on production capacity and needs.
4. Simple Structure and Easy Maintenance: The equipment is compact and easy to maintain and operate.
5. Hygiene Compliance: The equipment is primarily constructed of stainless steel and food-grade materials.
