Horizontal Cake Cutter Machine
video
Horizontal Cake Cutter Machine

Horizontal Cake Cutter Machine

Specially designed to cut horizontally cakes, it is ideal for slicing various shapes of cake ranging from circle, rectangle, roll, triangle, etc.
Send Inquiry
Chat Now

Product Introduction

Products Description

This horizontal layer cake slicer is specially designed for the precise and efficient cutting of cake products into horizontal slabs for the layer cake production line.
Cut off the top of the cake for a professional look with an even cut. Increase yield and reduce costs by baking one cake and slicing it into several thin layers to create a mille-feuille.



The standard tool distance of the machine is 15mm, that is, the thickness of the finished product is 15mm, and it can be adjusted in order of 15MM, 20MM, 25MM, and the interval of each adjustment is 5mm.
The machine is equipped with 4 blades, 3 are installed on the machine, and 1 is spare.

product-1-1

Product application and usage:

Specially designed to cut horizontally all cakes up to 48*63*(height custom)cm.
Premium Blades.
Comes with 3 cutting blades and 1 spare cutting blade.
Can be equipped with a maximum of 10 blades.
Adjustable conveyor speed.
Premium motor with high torque and low noise.
Overload and open phase protection.
Safety interlocks.
In compliance with GB4706.38-2003 and IEC60335-2-64: 1997.
Lockable casters.

product-1-1

Model

TPP - CG48

TPP-CG50

Capacity

About 2000 PCS/hr

About 2000pcs/hr

Power

0.37kw

1kw

Voltage

220 v, 50 hz, phase 1

220V, 50HZ, 1phase

Dimension

1270 * 780 * 1010 mm

1327*813*1100mm

Weight

150kg

150kg
